Specifications:
Model |
LiFePO4 Battery 36V 100Ah |
Nominal Voltage |
38.4V |
Nominal Capacity |
100Ah |
Energy |
3840Wh |
Cycle Life |
>5000 cycles |
Months Self Discharge |
<3% |
Efficiency of Charge |
100% @0.5C |
Efficiency of Discharge |
96~99% @0.5C |
BMS Functions |
Over charge, over discharge, over current, short circuit and temperature protection |
Charge Voltage |
42.6-43.8V |
Charge Mode |
0.2C to 43.8V, then 43.8V,charge current to 0.02C (CC/CV) |
Charge Current |
10A |
Max. Charge Current |
100A |
Max Continuous Discharge Current |
100A |
Peak Discharge Current |
250A 1-3S |
Discharge Cut-off Voltage |
30V±0.5V |
Charge Temperature |
0 ℃ to 55 ℃ (32F to 131F) @60±25% Relative Humidity |
Discharge Temperature |
-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity |
Storage Temperature |
-20 ℃ to 45 ℃ (-4F to 113F) @60±25% Relative Humidity |
IP Class |
IP65 |
Housing |
ABS Plastic Case |
Approx. Dimensions |
520x269x220mm (20.47''x10.59''x8.66'') |
Approx. Weight |
32kgs (70.55lbs) |
Applications:
* Solar/Wind Energy Storage Applications
* Back-up Power for UPS/ EPS
* RV, Caravan, Motor home
* Marine/ Yacht/ Fishing Boats
* Telecommunication/ Data Center Base
* DC Power Supply
* Auto Control System
* Power Tools
* Electric Toys
