Marine Batteries

Trolling motor battery 12v 200ah

Energy: 2560Wh
Working Current:200A(Max.)-500A(Peak)
Connections: max. 4pcs in serials and in parallels
Warranty: 5 Years
Product description: We're professional trolling motor batteries manufacturer and supplier in China, specialized in providing high quality lithium batteries for trolling motors and marine with competitive price. Our troll
INQUIRY

Trolling motor battery lifepo4 lithium battery 12v 200ah with smart battery management system (BMS) 5000+cycles 5 years warranty OEM with factory price

We're professional Lithium batteries manufacturer and supplier in China, specialized in providing high quality lithium batteries for trolling motors and marine with competitive price. Our trolling motor batteries include Lifepo4 12V, 24V, 36V series, which can not only drop-in-easy fro all kinds of trolling motors, but also can widely use for solar energy, RVs, VANs, yachts, fishing boats, and so on. All of our lithium batteries are made with grade A EV cells and smart BMS, promise 5000 cycles, 5 years warranty. We warmly welcome you to become a global dealer of our batteries. We can provide OEM service with your brand and offer competitive price for you to enlarge your maket share.

Please feel free to contact us for quote or cusotmization service

via email: sales@hi-powerbattery.com,

or via MOB/WhatsApp/WeChat: +86 19866617211 .

Specifications:

Model	LiFePO4 Battery 12V 200Ah
Nominal Voltage	12.8V
Nominal Capacity	200Ah
Energy	2560Wh
Cycle Life	>5000 cycles
Months Self Discharge	<3%
Efficiency of Charge	100% @0.5C
Efficiency of Discharge	96~99% @0.5C
BMS Functions	Over charge, over discharge, over current, short circuit and temperature protection
Charge Voltage	14.4±0.2V
Charge Mode	0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV)
Charge Current	20A
Max. Charge Current	100A
Max Continuous Discharge Current	200A
Peak Discharge Current	500A 1-3S
Discharge Cut-off Voltage	10V±0.5V
Charge Temperature	0 ℃ to 55 ℃ (32F to 131F) @60±25% Relative Humidity
Discharge Temperature	-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity
Storage Temperature	-20 ℃ to 45 ℃ (-4F to 113F) @60±25% Relative Humidity
IP Class	IP65
Housing	ABS Plastic Case
Approx. Dimensions	522x240x218mm (20.55''x9.45''x8.58'')
Approx. Weight	22kgs (48.50lbs)
