Rack-Mounted LiFePO4 Batteries

LiFePO4 48V 50Ah

51.2V 48V 50Ah LiFePO4 Lithium Battery for Solar Energy Storage Application

Specifications

Electrical Characteristics
Nominal Voltage	51.2V
Nominal Capacity	50Ah
Minimum Capacity	50Ah
Energy	2560Wh
Cycle Life	3000 cycles
Months Self Discharge	<3%
Efficiency of Charge	100% @0.5C
Efficiency of Discharge	96~99% @0.5C
BMS Functions	Over charge, over discharge, over current, short circuit and temperature protection
Communication Port	CAN, RS485
Standard Charge and Discharge
Charge Voltage	57.6-58.4V
Charge Mode	0.2C to 58.4V, then 58.4V,charge current to 0.02C (CC/CV)
Charge Current	10A
Max. Charge Current	50A
Charge Voltage	57.6-58.4V
Max Continuous Discharge Current	50A
Peak Discharge Current	150A 1-3S
Discharge Cut-off Voltage	40V±0.5V
Mechanical
Shell Material	SPCC
Approx. Dimensions	L(L1)482(442)xW(420)xH(133)mm
Approx. Weight	32kgs
Terminal Type	DW22 2P Wiring row *2
Environmental
Charge Temperature	0 ℃ to 55 ℃ (32F to 131F) @60±25% Relative Humidity
Discharge Temperature	-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity
Storage Temperature	-20 ℃ to 45 ℃ (-4F to 113F) @60±25% Relative Humidity
IP Class	IP20
